S80 Version 4.92 November 2014
Page 54 of 61
8.5.4 AHRS option
To activate AHRS, an activation code must be purchased.
AHRS option can be activated by the following procedure:
- Enter password 30000
- Enter 13-digit license key and confirm
If the code is correct, you will see an AHRS on AHRS page.
8.6 Ports and Wiring
8.6.1 LXNAV S80 ports
Static probe
Total pressure probe
(Pitot)
TE probe or
Static
Audio output
PDA port RJ45 type
GPS port RJ11
type
Main power supply
(V7 wiring)
