65
X-Y Pad
This chapter explains how to assign the axes of the X-Y pad to different commands. See the
Editing Assignments section to learn how to do this.
The axes’ functions also depend on their current modes. See the Modes section to learn
about their modes.
Editing Assignments
You can set the channel of each axis of the X-Y pad. See Channel to learn how to do this.
To learn how to assign different types of messages to an encoder, see the Messages section.
To learn how to set the X-Y pad’s response curve, see the Curve section.
Channel
To set the MIDI channel for an axis of the X-Y pad:
1. Press Edit to enter Edit Mode. The Edit button will light up.
2. Press the X button or Y button to select the desired axis. The axis letter will appear in the
display.
3. Press the Chan Assign key. The display will show CHN for 1 second and then show the
axis’s number and current MIDI channel or zone channel.
4. Use the numeric keys (0–9) or Preset Down/Up () buttons to enter the desired MIDI
channel (00 or 01–16) or zone channel (17–20).
Note: Values 00 and 01–16 correspond to Code 61’s global channel and the 16 available
MIDI channels. Values 17–20 correspond to channels used by Zones 1–4 (z1–z4).
5. Press the Enter key. The axis will be assigned to that channel, and you will exit Edit Mode.
To cancel your changes instead, press Edit. You will exit Edit Mode without saving anything.
Remember to store the preset if you want to save your changes in that preset.
