22
Operating Instructions
Signal description: Transmitter signals s1, s1/ and s2, s2/
Maximum frequency: 25kHz (Traverse rate = 0,5m/s at 20µm grid constant)
Signal amplitude: Current supply 4 to 16 µ
A
s s
.
In this way both the old Heidenhain specification 4 to 11
µAss
and the new
Heidenhain specification 7 to 11
µAss
are covered.
Connector types
Evaluation electronics
Measuring means
HELIOS-System
Circular connector
Flange socket connector
12-way round 09-0332-09-12
Connecting plug 12-way round
