Mahr GmbH, MarSurf M 300 and RD 18
27
Preparing for Meas urement4
4.1 Setting up the
Mobile Meas uring Station
To set up the drive unit:
1. Carefully insert the pick-up (25) into the
pick-up holder on the front face of the drive
unit (20); note the plug arrangement.
2. Screw the pick-up protection (24) firmly
onto the front face of the drive unit.
The pick-up protection should
be used at all times if possible
as it protects the pick-up from
damage.
Exception: When meas uring in
small-diameter bores or at points
that are difficult to access.
After changing the pick-up, the new
pick-up should be calibrated or its
correction value set (if it is known)
(see Section 5).
3. If necessary, assemble other accessories
such as the height adjustment – i. e. the
holder (26) and one or both vertical adjust-
ers (27) .
4. Place the drive unit in the correct meas uring
position by moving it longitudinally and ro-
tating it. Guide pins on the drive unit help to
find the ideal operating position.
2. Hold down the START key and select the
desired icon button by pressing the respec-
tive key. In this example:
Key combination • START + key 1.
The view with the function key assignments
will be displayed.
3. Press function key F1 or F2.
The new assignment is displayed in the bot-
tom status bar (e. g. "<F1> Save results").
The function key has been assigned the se-
lected function.
When a programmed function key is pressed,
the assigned function is displayed.
The function keys can be selected di-
rectly from most menus. However, if an
entry is being performed, this must be
quit first.
