Mahr GmbH, MarSurf M 300 and RD 18
35
Lc GS 0.800 mm
Rz 2.080 µm
Rmax 2.264 µm
Rzs 0.153 µm
Rz1 2.136 µm
Rz2 2.264 µm
Rz3 1.843 µm
Rz4 2.094 µm
Rz5 2.063 µm
55 56
Fig. 13
Rz list
55 Filter type
56 Cutoff Lc
In the Rz list, the mean peak-to-valley
height Rz is given in the first result line,
the maximum roughness depth Rmax
in the second line, and the standard de-
viation Rzs of the peak-to-valley height
values Rz1 to Rz5 in the third line. In the
fourth result line and beyond, the peak-
to-valley height values Rz1 to Rz5 from
the sampling lengths are listed.
23
The composition of the Rp list is analo-
gous to that of the Rz list.
23 For n ≠ 5 the resulting number of peak-to-valley height
values from the sampling lengths differs from 5.
