MAN B&W 8.05
Page 3 of 3
MAN Diesel
MAN B&W S46MC-C, S46ME-B, S42MC,
S35MC, S35MC-C, S35ME-B, L35MC, S26MC
198 70 356.0
Fig. 8.05.01: Example of a lubricating oil outlet to bottom tank, S46MC-C/ME-B and S42MC is shown
178 57 564.1
Lubricating oil outlet
An example of a lubricating oil outlet to bottom
tank is shown in Fig. 8.05.01.
2
6
2
1
3
4
5
Pos. 16 is yard’s supply
