Man B&W L35MC6-TII - Oil Mist Detector Pipes

MAN B&W 18.06
Page 2 of 5
MAN Diesel
MAN B&W MC/MC-C, ME/MEC/MEGI/ME-B engines 198 45 875.7
Cables
Detector head
Junction box
XS 8813 AH Y
Driving air connection
Exhaust air connection to crank space
Siphonblock
XS 8813 AH Y
Fig. 18.06.01a: Oil mist detector pipes on engine, type Graviner MK6 from Kidde Fire Protection (4 75 161)
178 49 809.3
Fig. 18.06.01b: Oil mist detector pipes on engine, type Visatron VN215/93 from Schaller Automation (4 75 163)
178 49 810.3
