MAN B&W 2.07
Page 1 of 1
MAN Diesel
198 70 11-6.0MAN B&W S46MC-C7/8-TII, S42MC7-TII, S40MC-C9-TII,
S35MC7-TII, S35MC-C9-TII, L35MC6-TII, S26MC6-TII
SFOC for Conventional Turbochargers
All engine types 46 and smaller are as standard
fitted with conventional turbochargers, option:
4 59 107.
The conventional turbocharger is applied to the
engine in the basic design with the view to obtain-
ing the best possible Specific Fuel Oil Consump-
tion (SFOC) values, see example in Fig. 2.07.01.
Fig. 2.07.01: Example of part load SFOC curves for conventional turbochargers
178 61 00-3.0
Engine power, % of optimising point O
50%
60%
70%
80% 90% 100%
SFOC
g/kWh
0
+2
2
4
Conventional turbocharger
At part load running the lowest SFOC may be
obtained at 80% of the optimised power = 80%
of the specified MCR.
