Man B&W L35MC6-TII - Forces and Moments at Turbocharger; Turbocharger Located on Aft End; Vectors of Thermal Expansion; Max. Expected Movements of the Exhaust Gas Flange

MAN B&W 15.06
Page  of 3
MAN Diesel
198 64 13-7.0
MAN B&W L35MC6
Forces and Moments at Turbocharger
Turbocharger located on aft end
$#
$!
!FT #YLæ
Fig. 15.06.01a: Vectors of thermal expansion at the turbocharger exhaust gas outlet ange, TC on aft end
078 87 11-1.0.0a
Table 15.06.02a: Max. expected movements of the exhaust gas ange resulting from thermal expansion, TC on aft end
No. of cylinders 5-9 5 6 7 8 9
Turbocharger DA DC DC DC DC DC
Make Type mm mm mm mm mm mm
MAN Diesel
NA34 4.5 .7 .9 2.0 2. 2.3
NA40 5.0 .9 2. 2.2 2.3 2.4
ABB
TPL65 4. .6 .7 .8 2.0 2.
TPL69 4.5 .7 .9 2.0 2. 2.2
TPL73 4.9 .9 2.0 2. 2.3 2.4
MHI
MET33 4.0 .6 .8 .9 2.0 2.
MET42 4.5 .8 .9 2. 2.2 2.3
MET53 5.2 2. 2.2 2.4 2.5 2.6
DA: Max. movement of the turbocharger ange in the vertical direction
DC: Max. movement of the turbocharger ange in the longitudinal direction
