MAN B&W 12.03
Page 1 of 1
MAN Diesel
MAN B&W S60MC, S/L60MC-C, S60MEC/ME-GI/ME-B, L60MEC,
S50MC/MC-C, S50MEC/ME-B, S46MC-C, S46ME-B, S42MC,
S40MC-C9, S40ME-B, S35MC-C9, S/L35MC, S35ME-B, S26MC
198 39 788.6
Seawater Cooling Pipes
Scavenge
air cooler
AS
AS
P
N
TI 8422
TI 8423
TE 8422 I
PI 8421
PT 8421 I AL
TE 8423 I
178 50 387.1
Fig. 12.03.01: Seawater cooling pipes for engines with one turbocharger
The letters refer to list of ‘Counterflanges’
The item No. refer to ‘Guidance values automation’
