MAN Diesel
MAN B&W L35MC6 198 66 28-3.0
Large spare parts, dimensions and masses
Pos Sec. Description
Mass Dimensions (mm)
(kg) A B C D E
 Cylinder liner, incl. cooling jacket 374 ø440 ø470 ,25 ø400
2 Exhaust valve 96 937 426 350
3 Piston complete, with piston rod 278 ø350 20 ø30 ,593 240
4 Cylinder cover, incl. valves 305 ø60 225
5 Rotor for turbocharger, TCR20-2 39 ø337 566
5 Rotor for turbocharger, TCR22-2/25 87 ø440 739
5 Rotor for turbocharger, 65-BA0 Available on request
5 Rotor for turbocharger, 69-BA0 6 ø40 788
5 Rotor for turbocharger, TPL73-B 5 ø489 963
5 Rotor for turbocharger, MET33MA 45 ø373 662
5 Rotor for turbocharger, MET42MA 69 ø462 807
Fig. 19.09.01: Large spare parts, dimensions and masses
178 39 45-8.3
!
"
%
!
"
#
$
!
"
#
!
#
$
!
"
"
 



