Man B&W L35MC6-TII

MAN B&W 18.04
Page 5 of 7
MAN Diesel
MAN B&W MC/MCC engines 198 62 364.2
Alarms for UMS – Class and MAN Diesel requirements
ABS BV CCS DNV GL KR LR NK RINA RS IACS MAN Diesel
Sensor and
function Point of location
Exhaust gas
1 1 1 1 1 1 (1) 1 1 1 1 1 TC 8701 AH Exhaust gas before turbocharger/turbocharger
1 1 1 1 1 1 1 1 1 1 TC 8702 AH Exhaust gas after exhaust valve, cylinder/cylinder
1 1 1 1 1 1 1 1 1 1 1 TC 8707 AH Exhaust gas outlet turbocharger/turbocharger (Yard’s
supply)
Miscellaneous
1 ZT 8801 AH Turbocharger overspeed
1 WT 8805 AH Vibration of turbocharger
1 WT 8812 AH Axial vibration monitor 2)
1 1 1 1 1 1 1 1 1 1 1 XS 881 AH Oil mist in crankcase/cylinder; sensor common for
XS 881/14
1 1 XS 8814 AL Oil mist detector failure
1 XC 8816 I Shaftline earthing device
1 TE 8820 AH Cylinder liner monitoring/cylinder )
1 Indicates that the sensor is required.
The sensors in the MAN Diesel column are included for Unattended Machinery Spaces (UMS), option: 4 75 127.
The sensor identication codes and functions are listed in Table 18.07.01.
The tables are liable to change without notice, and are subject to latest class requirements.
(1) May be combined with TC 8702 AH where turbocharger is mounted directly on the exhaust manifold.
2) Required for: K-MC-C6/7 and K98MC6/7 engines with 11 and 14 cylinders.
S-MC-C7/8 and L-MC-C7/8 engines with 5 and 6 cylinders.
(For 9-12 cylinder S42MC7, L5MC6, and S26MC6 data is available on request).
) Required for: K98MC/MC-C6/7, S90MC-C7/8 and K90MC-C6 engines
Alarm for overheating of main, crank and crosshead bearings, option: 4 75 14.
Table 18.04.02c: Alarm functions for UMS
