Special tools
172
Special tool for removing and fitting injectors
48
49.1
49.2
49.3
49.4
49.5
49.6
50
51 52
53
Fig. no. Designation Item number
48 Ring socket tool for fitting the claw in conjunction with 20.1 08.06455−0026
49.1 Torque wrench 08.06510−9024
49.2 Adapter 08.06139−9029
49.3 Extension 08.06139−9007
49.4 Magnetic lifter for removing pressure pipe fittings 80.99639−0009
49.5 Wrench socket for injector cable connection 08.06141−0700
49.6 Wrench socket for injector pressure flange 08.06141−1300
50 Bridge with adjustable supports 80.99602−6017
51 Extractor device for injectors 80.99601−6022
52 Thrust member for fitting injectors 80.99606−0609
53 Set of protective sleeves, injection system 80.96002−6005
