17
18
19
20
Removing and installing valves
91
Fig. 17
Press in the valve stem seal as far as it will go.
Remove the guide sleeve.
Fig. 18
Mount the valve springs and spring seats.
Fig. 19
Fit guide sleeve à over the valve spring for cen-
tring.
Mount anchor plate Á and guide sleeve  from the
special tool kit.
Insert the retaining wedges in mounting cartridge
Æ.
Fig. 20
Insert the mounting cartridge in the guide sleeve
and press down with pressure fork Ä as far as it
will go.
Release the pressure fork and remove the mount-
ing cartridge.
3
2
7
5
