500H-PERIODIC SERVICE-EVERY 500 HOURS OF SERVICE OR1 YEAR
- CHECK Hydraulic oil ........................................................................................ 3-20
- GREASE Mast lifting chains .................................................................................. 3-20
- LUBRICATE Cab door locks (OPTION) ............................................................................ 3-20
- REPLACE Engine oil........................................................................................... 3-21
- REPLACE Engine oil filter...................................................................................... 3-21
- REPLACE Fuel pre-filter ....................................................................................... 3-22
- REPLACE Fuel filter ........................................................................................... 3-22
- REPLACE Alternator belt ...................................................................................... 3-23
- REPLACE Hydraulic return oil filter cartridge................................................................... 3-23
- REPLACE Cab fan filters (OPTION) ............................................................................. 3-24
- CHECK Hoses and differential pressure hoses for the exhaust particle filter "DPF" **........................... 3-24
- CHECK Exhaust gas recirculation piping "EGR" ** ............................................................ 3-24
- CHECK Intake hose **....................................................................................... 3-24
- CHECK Exhaust manifold **................................................................................. 3-24
- CHECK Fork wear * ......................................................................................... 3-24
** Engine service, consult your dealer.
* Consult your dealer.
PERIODIC SERVICE
MAINTENANCE SCHEDULE
ÄORÄ
WHEN DUE
Â
FIRST 6 MONTHS FIRST 500 HOURS
500 H
or1 YEAR
1000 H
or 2 YEARS
1500 H
or 3 YEARS
2000 H
or 4 YEARS
PERIODIC SERVICE
Â
MANDATORY SERVICE
MANDATORY SERVICE
+
n
nn
+
onn
+
o
+
p
MACHINE COUNTER
Â
DATE OF SERVICING
Â
WHEN DUE
Â
2500 H
or 5 YEARS
3000 H
or 6 YEARS
3500 H
or 7 YEARS
4000 H
or 8 YEARS
4500 H
or 9 YEARS
5000 H
or10YEARS
5500 H
or11YEARS
PERIODIC SERVICE
Â
nn
+
o
+
qnn
+
o
+
pn n
+
on
MACHINE COUNTER
Â
DATE OF SERVICING
Â
WHEN DUE
Â
6000 H
or 12 YEARS
6500 H
or 13 YEARS
7000 H
or 14 YEARS
7500 H
or 15 YEARS
8000 H
or16YEARS
8500 H
or17YEARS
9000 H
or 18 YEARS
PERIODIC SERVICE
Â
n
+
o
+
p
+
q
nn
+
onn
+
o
+
pnn
+
o
+
q
MACHINE COUNTER
Â
DATE OF SERVICING
Â
