Manitowoc Grove GRT8100 Service Manual

4-17
Published 3/26/2018, Control # 596-05
GRT8100 SERVICE MANUAL BOOM
4
GROVE
Item Description
1 BASE SECTION WELD
2 TELE 1 WELD
3 TELE 2 WELD
4 TELE 3 WELD
5 TELE 4 WELD
6 CYL HYD, DISCRETE CTL 2 STAGE
7 WEAR PAD
8 SHIM
9 KEEPER PLATE
10 F WASHER, 12 ST ISO 7089
11 L WASHER, 12 ST DIN 7980
12 Hex Nut M12 8 ISO 4032
13 HHCS M12x40 8.8 ISO 4017
14 STOP BLOCK IMID
15 SHIM
16 F WASHER 5/8” HARD ASTM F-436
17 Hex Nut M16 8 ISO 4032
18 SHCS M16x50 10.9 ISO 4762
19 WEAR PAD ASSEMBLY
20 KEEPER PLATE
21 Hex Jam Nut M20 04 ISO 4035
22 HHCS M20x50 10.9 ISO 4014
23 Protection strip G-Nr.3006000-
24 HHCS M12x100 8.8 ISO 4014
25 PAT BRACKET
26 MOUNTING ANGLE
27 F WASHER, 8 ST ISO 7089
28 L WASHER, 8 ST DIN 7980
29 HHCS FULL THREAD, 8 X 25 8.8
30 HEX NUT, 8.8 ISO 4032
31 HHCS M8x30 8.8 ISO 4017
32 BOOM CABLE GUIDE ASS’Y
33 F WASHER 3/4” HARD ASTM F-436-
34 HITCH PIN CLIP
35 PLATE
36 STRAIGHT THREAD ADAPTER
37 ORS BRANCH TEE
38 TUBE ASSY
39 TELE STAGE SELECT VALVE
40 HHCS M12x160 8.8 ISO 4014
41 O-RING 1”
42 SPLIT FLANGE HALF
43 HHCS 3/8-16UNCx1.25 G5
44 WEAR PAD
45 SHIM
46 WEAR PAD ASSEMBLY
47 ANCHOR WELD
48 F Washer 1” Hard
49 Hex Nut M24 8 ISO 4032
50 F WASHER, 20 ST ISO 7089
51 Hex Nut M20 8 ISO 4032
52 HHCS M20x40 -10.9 ISO 4014
53 WEAR PAD
54 WEAR PAD
55 SPACER
56 HHCS M10x25 SS ISO 4017
57 ANCHOR BLOCK
58 1-1/4” BOLT (16.00” LONG)
59 F Washer 1-1/4” Hard ASTM F-43
60 Hex Nut 1-1/4-7UNC SAE-8
61 KEEPER PLATE
62 HHCS M6x16 SS ISO 4017
63 WEAR PAD
64 WEAR PAD
65 SHIM
66 Adapter 304-19509-1 M10x1/M10x
67 Pipe union SV-06L/SW17 M12x1
68 Thin nut M12x1.5 5 DIN 80705
69 Elbow, Push-in 226-14123-3 WEK
70 LUBRICANT HOSE L=500
71 TRUNNION PLATE
72 F Washer 1-1/8” Hard ASTM F-43
73 HHCS M30x55 10.9 ISO 4017
74 HHCS M20x80 8.8 ISO 4017
75 SHIM
76 WEAR PAD
77 KEEPER PLATE
78 WEAR PAD ASSEMBLY
79 PROTECTION STRIP G-NR.3006000-
80 HHCS M12x80 8.8 ISO 4014
81 SHEAVE ASSEMBLY
82 SHAFT WELD
83 Thrust Washer 1.75x2.6x0.13” B
84 GUARD WELD
85 HHCS M8x16 SS ISO 4017
86 90DEG GREASE FITTING
87 CABLE 14MM RETRACT
88 Hex Nut M30 8 ISO 4032
