Manitowoc Grove GRT8100 Service Manual

BOOM GRT8100 SERVICE MANUAL
4-18
Published 3/26/2018, Control # 596-05
89 SHAFT
90 ROLLER ASSEMBLY
91 F Washer 5/16” Wide MS
92 TRUNNION PLATE
93 SHIM
94 WEAR PAD
95 WEAR PAD
96 WEAR PAD
97 SHIM
98 WEAR PAD
99 WEAR PAD
100 WEAR PAD ASSEMBLY
101 SHAFT
102 SHEAVE ASSEMBLY
103 SHEAVE ASSEMBLY
104 CABLE 16MM EXTEND
105 CABLE 16MM EXTEND
106 GUARD WELD
107 GUARD WELD
108 HHCS M16x50 10.9 ISO 4017
109 LUBE NIPPLE A M10x1 5.8-A3C
110 KEEPER PLATE
111 HHCS M12x30 10.9 ISO 4017
112 SHEAVE MOUNT WELD
113 HHCS M16x40 10.9 ISO 4017
114 CABLE 14MM RETRACT
115 SHAFT
116 F Washer 1” Nar MS
117 SHAFT
118 KEEPER PLATE
119 F WASHER, 10 ST ISO 7089
120 L WASHER, 10 ST DIN 7980
121 HHCS M12x16 8.8-A3C ISO 4017
122 CYL WEAR PAD
123 HHCS M10x16 SS ISO 4017
124 SHIM
125 WEAR PAD
126 WEAR PAD
127 WEAR PAD
128 WEAR PAD
129 HHCS M10x45 8.8 ISO 4017
130 SHIM
131 WEAR PAD
132 WEAR PAD
Item Description
133 SHEAVE MOUNT WELD
134 SHEAVE ASSY - 2 GROOVE
135 SPACER-154mm I.D.
136 SHAFT
137 PLATE
138 F WASHER 1/2” HARD ASTM F-436
139 CABLE 19MM EXTEND
140 CABLE KEEPER
141 HHCS FULL THREAD, 12 X 25 8.8
142 WEAR PAD
143 WEAR PAD
144 HHCS M12x140 8.8 ISO 4014
145 WEAR PAD
146 HHCS M12x55 8.8 ISO 4017
147 CABLE KEEPER
148 TRUNNION BLOCK
149 RUN TEE ORFS/BSPP/ORFS
150 ELBOW-MALE ORFS TO MALE BSPP
151 TUBE ASSY TELE DRAIN
152 PRESSURE TRANSDUCER
153 TUBE ASSY
154 TUBE ASSY
155 SPLIT FLANGE HALF
156 HHCS 7/16-14UNCx1.75 G5
157 STRAIGHT THREAD ELBOW 90 DEGRE
158 COVER PLATE
159 F Washer 1/4” Wide MS
160 L Washer 1/4” Reg
161 HHCS 1/4-20UNCx0.75 G5
167 PLATE
168 HHCS M16x30 -8.8 ISO 4017
169 BRACKET
170 HHCS M12x45 8.8 ISO 4014
171 LUBRICANT HOSE L=420
172 SPACER
173 PLATE
200 WEAR PAD KIT
Item Description
