GRT8100 SERVICE MANUAL HYDRAULIC SYSTEM
2
Published 3/26/2018, Control # 596-05
FIGURE 2-18
Valve Installation - Superstructure
1 Compact Manifold Valve
2 Main Directional Manifold Valve
3 Accessory Manifold Valve
4 Swing Manifold Valve
5 Dual Accumulator Charge Manifold Valve
6 Brake Accumulators
2
1
4
3
5
8804-80
6
