2. The digital intelli-
gent
AC servo drive with
ANALOG interface
2. The digital intelligent AC servo drive with ANALOG interface
Fig. 4: Digital AC servo drives combined to form a modular drive package
Digital intelligent AC servo drives are of modular construction.
The modular principle allows flexible combination of AC servo drives and
AC main spindle drives of different power ratings to form compact drive
packages with one common power supply module.
The available power supply modules for AC servo drives may be
connected up directly to international three-phase power mains of 3 x AC
(380 to 460) V, (50-60) Hz.
A digital intelligent AC servo drive consists in each case of a carefully
matched combination of AC servo motor MDD and a DDS 2.1 drive
controller.
