Marantz PM-14S1 User Manual

5
Connections Playback Settings Tips Appendix
ENGLISH
Preparation
q SIGNAL GND (ground) terminal
Usedtoconnecttheearthwireofaturntable.
NOTE
Thisterminalisnotasafetyground.
w Audio input connectors (AUDIO IN)
Used to connect devices equipped with analog audio
connectors(vpage8).
e Input/output connectors (Recordings)
(RECORDER-1, RECORDER-2)
Usedtoconnecttoarecordingdevice(vpage9).
r Speaker system terminals
(SPEAKER SYSTEMS)
Usedtoconnectspeakers(vpage7).
t REMOTE CONTROL connectors
UsedtoconnecttoaMarantzaudiodevicethatiscompatible
withtheremotecontrolfunction(vpage15).
Rear panel
Q0 o
q t y u iw e r
y AMPLIFIER MODE switch
Used to switch the amplier mode (STEREO/BI-AMP)
(vpage11,12).
u F.C.B.S. connectors
Usedtoconnectahighqualityplaybacksystemusingtwo
ormoreoftheseunits(vpage10).
i AC inlet (AC IN)
Usedtoconnectthepowercord(vpage15).
o Power amplifier direct connectors
(POWER AMP DIRECT IN)
Usedtoconnectapre-amplierwhenthisunitisusedasa
poweramplier(vpage14).
Q0 PRE OUT connectors
Use this to add such equipment as a power amplier or
subwoofer(vpage14).
Part names and functions
1.PM14S1N_ENG_Final_0708.indd 5 2013/07/11 19:14:03

Marantz PM-14S1 Specifications

General

Receiver type	-
Frequency range	5 - 100000 Hz
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (4 Ohm)	140 W
Dynamic power per channel (8 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	- W
Headphone outputs	1
Headphone connectivity	6.3 mm
Ethernet LAN	No
Display	LCD
Product color	Gold
Apple docking compatibility	Not supported
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	220 W
Cables included	AC

Weight and Dimensions

Depth	453 mm
Width	440 mm
Height	123 mm
Weight	18500 g
