Marantz PM-14S1 User Manual

22
ENGLISH
n No sound comes out
Symptom Cause Page
Nosoundcomesoutofspeakers. •Checktheconnectionsforalldevices.
•Insertconnectioncablesallthewayin.
•Checkthatinputconnectorsandoutputconnectorsarenotreverselyconnected.
•Checkcablesfordamage.
•Checkthatspeakercables are properly connected. Check that cable core wires come in contact with the metal part on
speakerterminals.Also,securelytightenspeakerterminals.Checkspeakerterminalsforlooseness.
•Checkthataproperinputsourceisselected.
•Adjustthevolume.
•Cancelthemutemode.
7
–
–
–
7
16
16
17
n Desired sound does not come out
Symptom Cause Page
Nosoundcomesoutofaspecicspeaker. •Checkthatthespeakercableisproperlyconnected.
•Adjusttheleftandrightchannelbalance.
7
17
Theleftandrightofstereosoundisreversed. •Checkwhethertheleftandrightspeakersareconnectedtothecorrectspeakerterminals. 7
n Sound is interrupted or noise occurs
Symptom Cause Page
Whenplayingarecord,thesoundisdistorted. •Adjusttoaproperneedlepressure.
•Checkthetipoftheneedle.
•Replacethecartridge.
–
–
–
Whenplayingarecord,ahummingnoise
comesoutofthespeakers.
•Checkthattheturntableisconnectedcorrectly.
•IfthereisaTVorAVdeviceneartheturntable,suchdevicesmayaecttheplaybacksound.Installtheturntableinalocation
asfarawayaspossiblefromtheTVorotherAVdevices.
8
–
Whenplayingarecordathighvolume,a
“howling”soundcomesoutofthespeakers.
•Installtheturntableandspeakersasfarfromeachotheraspossible.
•Thevibrationsfromthespeakersarebeingtransmittedtotheplayerthroughtheoor.Usecushions,etc.,toabsorbthe
speakers’vibrations.
8
–
Troubleshooting
1.PM14S1N_ENG_Final_0708.indd 22 2013/07/11 19:14:19

Marantz PM-14S1 Specifications

General

Receiver type	-
Frequency range	5 - 100000 Hz
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (4 Ohm)	140 W
Dynamic power per channel (8 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	- W
Headphone outputs	1
Headphone connectivity	6.3 mm
Ethernet LAN	No
Display	LCD
Product color	Gold
Apple docking compatibility	Not supported
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	220 W
Cables included	AC

Weight and Dimensions

Depth	453 mm
Width	440 mm
Height	123 mm
Weight	18500 g
