Connecting P.DIRECT IN connectors
Ifyouuseapre-amplier,connectitasshownbelow,andthenyoucanusethisunitasapower
amplier.
Press and hold P.DIRECT IN on the unit for 3 seconds or longer.
•Thepowerampdirectmodesettingchangeswitheachpressofthebutton.
•Ifthemodeissettoon,thedisplayshows“POWERAMPDIRECT”.
On :AllowsthedeviceconnectedtothePowerAmpDirectconnectortobeplayed.
O (Default):AllowstheprogramsourceselectedusingINPUTSELECTORtobeplayed.
(R) (L)
L
R
L
R
Pre-amplifier
Speakers
ToPREOUTconnectors
NOTE
•Whenthepowerampdirectmodeison,adjustmentofthevolume,balanceandtoneonthe
mainunithasnoeect.Adjustthevolumeonthepre-amplier.
•Whenthepowerampdirectmodeison,themainunitoutputsatmaximumvolume.Check
theoutputlevelontheinputdevicebeforeplayingitandadjustthevolumeaccordingly.
Connecting PRE OUT connectors
Ifyouuseapoweramplier,connectitasshownbelow,andthenyoucanusethisunitasa
pre-amplier.
•For connecting speaker systems, refer to the owner’s manual  supplied with the power
ampliertobeused.
Power-amplifier
R
L
R
L
Toinputconnectors
NOTE
ThepowerampdirectmodeandthePREOUTfunctioncannotworkatthesametime.
