11. MICROPROCESSOR AND IC DATA
Pin
No
Port
mode=7
I/O Use STBY Name Port
Setting
Note
Act. init
1 PE5 I/O O I - - NC
2 PE6 I/O I I SEL+ - - SELECT ENCODER +
3 PE7 I/O I I SEL- - - SELECT ENCODER -
4 PD0 I/O I I GYRO+ - - GYRO ENCODER +
5 PD1 I/O I I GYRO- - - GYRO ENCODER -
6 PD2 I/O I I VOL+ - - VOLUME ENCODER +
7 PD3 I/O I I VOL- - - VOLUME ENCODER -
8 PD4 I/O I I _HP_DET L - HEAD PHONE PLUG IN DET
9 PD5 I/O O I HP_ON H L HEAD PHONE RELAY CONT
10 PD6 I/O O I FLRA_ON H L FRONT L/R SPK A RELAY CONT
11 PD7 I/O O I FLRB_ON H L FRONT L/R SPK B RELAY CONT
12 Vss I I I VSS - - GND
13 PC0 I/O O I 3SPK_ON H L C/SL/SR SPK RELAY CONT
14 P1Vcc I YES I VCC - - +3.3V
15 PC1 I/O O I SB_ON H L SBL/SBR SPK RELAY CONT
16 PC2 I/O O I (MSPK_ON) - - MULTI SPK RELAY CONT
17 PC3 I/O I I _AVSS_DET L - AVSS DET
18 PC4 I/O O I AVSS_OUT H L AVSS RELAY CONT
19 PC5 I/O O I _STANDBY2 L H STAND BY CONTROL 2
20 PC6 I/O O I - - NC
21 PC7 I/O O I - - NC
22 PB0 I/O O I USB_CSDAO - - DATA OUT FOR USB CONT DATA OUT
23 PB1 I/O O I - - NC
24 PB2 I/O O I - - NC
25 PB3 I/O I I USB_PLL_UL L - USB MUTE CONT PLL UNLOCK
26 PB4 I/O O I - - NC
27 PB5 I/O O I _SUB_CPU_DL L H DOWNLOAD CONT FOR SUB CPU
28 PB6 I/O O I _SUB_CPU_RST L H RESET FOR SUB CPU
29 PB7 I/O O I _MRAC_CPU_DL L H DOWNLOAD CONT FOR MRAC CPU
30 PA0 I/O O I _MRAC_CPU_RST L H RESET FOR MRAC CPU
31 PA1 I/O O I _GUI_CPU_DL L H DOWNLOAD CONT FOR GUI CPU (ONLY
SR-10)
32 PA2 I/O O I _GUI_CPU_RST L H RESET FOR GUI CPU (ONLY SR-10)
33 PA3 I/O O I _1394_CPU_DL L H DOWNLOAD CONT FOR 1394 CPU (ONLY
SR-10)
34 PA4 I/O O I _1394_CPU_RST L H RESET FOR 1394 CPU (ONLY SR-10)
35 PA5 I/O O I EE_SCL - - SCL FOR EE-PROM CLK
36 PA6 I/O I/O I EE_SDA - - SDA䇭FOR EE-PROM DATA
37 PA7 I/O O I AUD_MUTE - - AUDIO MUTE SWITCH
38 PH7 I/O O I - - NC
39 PH6 I/O O I - - NC
40 PH5 I/O O I - - NC
41 PH4 I/O O I - - NC
42 PH3 I/O O I - - NC
43 PH2 I/O O I - - NC
44 PH1 I/O O I - - NC
45 PH0 I/O O I - -
46 PJ7 I/O O I - - NC
47 PJ6 I/O I I 232C_CTS - - 232C_CTS FOR DOWNLOAD
48 PJ5 I/O O I 232C_RTS - - 232C_RTS FOR DOWNLOAD
49 PJ4 I/O O I - - NC
50 PJ3 I/O O I DC_OUT1 L H DC TRIGER OUT 1
QW01 : HD64F2505FC26DV (MAIN)
