Marantz SR9600 - Electrical Parts List

214213
The suppliers and their type numbers of fusible resistors
are as follows;
1. KOA Corporation
Part No. (MJI) Type No. (KOA) Description
00MNH05 × × × 140 RF25S × × × × ΩJ(±5% 1/4W)
00MNH05 × × × 120 RF50S × × × × ΩJ(±5% 1/2W)
00MNH85 × × × 110 RF73B2A × × × × ΩJ(±5% 1/10W)
00MNH95 × × × 140 RF73B2E × × × × ΩJ(±5% 1/4W)
2. Matsushita Electronic Components Co., Ltd
Part No. (MJI) Type No. (MEC) Description
00MNF05 × × × 140 ERD-2FCJ × × × (±5% 1/4W)
00MRF05 × × × 140
00MNF02 × × × 140 ERD-2FCG × × × (±2% 1/4W)
00MRF02 × × × 140
Examples ;
Resistance value
0.1 Ω .... 001 10 Ω .... 100 1 kΩ .... 102 100 kΩ .... 104
0.5 Ω .... 005 18 Ω .... 180 2.7 kΩ .... 272 680 kΩ .... 684
1 Ω .... 010 100 Ω .... 101 10 kΩ .... 103 1 MΩ .... 105
6.8 Ω .... 068 390 Ω .... 391 22 kΩ .... 223 4.7 MΩ .... 475
PARTS INFORMATION
RESISTORS
1) 00MGD05 × × × 140, Carbon film fixed resistor, ±5% 1/4W
2) 00MGD05 × × × 160, Carbon film fixed resistor, ±5% 1/6W
Examples ;
Resistance value
0.1 Ω .... 001 10 Ω .... 100 1 kΩ .... 102 100 kΩ .... 104
0.5 Ω .... 005 18 Ω .... 180 2.7 kΩ .... 272 680 kΩ .... 684
1 Ω .... 010 100 Ω .... 101 10 kΩ .... 103 1 MΩ .... 105
6.8 Ω .... 068 390 Ω .... 391 22 kΩ .... 223 4.7 MΩ .... 475
Note : Please distinguish 1/4W from 1/6W by the shape of parts
used actually.
CAPACITORS
CERAMIC CAP.
3) 00MDD1 × × × × 370 Ceramic capacitor
Disc type
Temp.coeff.P350 N1000, 50V
Examples ;
Tolerance (Capacity deviation)
±0.25 pF .... 0
±0.5 pF .... 1
±5% .... 5
Tolerance of COMMON PARTS handled here are as follows :
0.5 pF 5 pF .... ±0.25 pF
6 pF 10 pF .... ±0.5 pF
12 pF 560 pF .... ±5%
Capacity value
0.5 pF .... 005 3 pF .... 030 100 pF .... 101
1 pF .... 010 10 pF .... 100 220 pF .... 221
1.5 pF .... 015 47 pF .... 470 560 pF .... 561
CERAMIC CAP.
4) 00MDK16 × × × 300, High dielectric constant ceramic
capacitor
Disc type
Temp.chara. 2B4, 50V
Examples ;
Capacity value
100 pF .... 101 1000 pF .... 102 10000 pF .... 103
470 pF .... 471 2200 pF .... 222
ELECTROLY CAP. ( ) .
5) 00MEA
× × × × × × 10, Electrolytic capacitor
One-way lead type, Tolerance ±20%
Examples ;
Capacity value
0.1 µF .... 104 4.7 µF .... 475 100 µF ....107
0.33 µF .... 334 10 µF .... 106 330 µF ....337
1 µF.... 105 22 µF ....226 1100 µF ....118
2200 µF ....228
Working voltage
6.3V .... 006 25V .... 025
10V .... 010 35V .... 035
16V .... 016 50V .... 050
6) 00MDF15 × × × 350 Plastic film capacitor
00MDF15 × × × 310 One-way type, Mylar ±5% 50V
00MDF16 × × × 310 Plastic film capacitor
One-way type, Mylar ±10% 50V
Examples ;
Capacity value
0.001 µF (1000 pF) ....... 102 0.1 µF .... 104
0.0018 µF ........................ 182 0.56 µF .... 564
0.01 µF ........................ 103 1 µF .... 105
0.015 µF ........................ 153
➀
➁
Capacity value
Tolerance
➃
Capacity value
Resistance value
➄
Working voltage
Capacity value
➆
Capacity value
NOTE ON SAFETY FOR FUSIBLE RESISTOR :
Resistance value
Resistance value
(0.1 Ω − 10 kΩ)
Resistance value
Resistance value
ANT. : ANTENNA BATT. : BATTERY
CAP. : CAPACITOR CER. : CERAMIC
CONN. : CONNECTING DIG. : DIGITAL
HP : HEADPHONE MIC. : MICROPHONE
µ-PRO : MICROPROCESSOR REC. : RECORDING
RES. : RESISTOR SPK : SPEAKER
SW : SWITCH TRANSF. : TRANSFORMER
TRIM. : TRIMMING TRS. : TRANSISTOR
VAR. : VARIABLE X’TAL : CRYSTAL
ABBREVIATION AND MARKS
{
FILM CAP.
( )
{
{
{
{
{
{
{
{
{
➂
➀
➁
➂
➃
➄
➅
➆
➅
NOTE ON SAFETY :
Symbol Fire or electrical shock hazard. Only original
parts should be used to replaced any part marked with
symbol . Any other component substitution (other
than original type), may increase risk of fire or electrical
shock hazard.
NOTE ON FUSE :
Regarding to all parts of parts code 00MFS20xxx2xx, replace
only with Wickmann-Werke GmbH, Type 372 non glass type
fuse.
040623ecm
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POWER AMP1 PWB
(
00MWA12AJ101-
)
P114 C101 ns
p
00MOA22602540 ELECT. CAP. 22 UF M 25V ARS-TYPE ELN
A
P114 C102 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J,330PF
(
TP
)
100V PP
P114 C103 ns
p
00MOA10705020 ELECT. CAP. 100 UF M 50V RA-2
P114 C104 00MOF15332540 00MOF15332540 FILM CAP. APSV 332J 3300PF
(
TF
)
100V P
P
P114 C105 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P114 C106 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P114 C107 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P114 C108 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P114 C111 00MOF55100590 00MOF55100590 FILM CAP. 10PF 200V +- 5% FAS
P114 C112 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P114 C113 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P114 C148 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P114 C149 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P114 C201 ns
p
00MOA22602540 ELECT. CAP. 22 UF M 25V ARS-TYPE ELN
A
P114 C202 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J,330PF
(
TP
)
100V PP
P114 C203 ns
p
00MOA10705020 ELECT. CAP. 100 UF M 50V RA-2
P114 C204 00MOF15332540 00MOF15332540 FILM CAP. APSV 332J 3300PF
(
TF
)
100V P
P
P114 C205 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P114 C206 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P114 C207 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P114 C208 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P114 C211 00MOF55100590 00MOF55100590 FILM CAP. 10PF 200V +- 5% FAS
P114 C212 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P114 C213 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P114 C248 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P114 C249 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P114 C301 ns
p
00MOA22602540 ELECT. CAP. 22 UF M 25V ARS-TYPE ELN
A
P114 C302 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J,330PF
(
TP
)
100V PP
P114 C303 ns
p
00MOA10705020 ELECT. CAP. 100 UF M 50V RA-2
P114 C304 00MOF15332540 00MOF15332540 FILM CAP. APSV 332J 3300PF
(
TF
)
100V P
P
P114 C305 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P114 C306 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P114 C307 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P114 C308 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P114 C311 00MOF55100590 00MOF55100590 FILM CAP. 10PF 200V +- 5% FAS
P114 C312 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P114 C313 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P114 C348 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P114 C349 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P114 C401 ns
p
00MOA22602540 ELECT. CAP. 22 UF M 25V ARS-TYPE ELN
A
P114 C402 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J,330PF
(
TP
)
100V PP
P114 C403 ns
p
00MOA10705020 ELECT. CAP. 100 UF M 50V RA-2
P114 C404 00MOF15332540 00MOF15332540 FILM CAP. APSV 332J 3300PF
(
TF
)
100V P
P
P114 C405 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P114 C406 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P114 C407 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P114 C408 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P114 C411 00MOF55100590 00MOF55100590 FILM CAP. 10PF 200V +- 5% FAS
P114 C412 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P114 C413 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P114 C448 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P114 C449 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P114 CN35 00MDF15103350 00MDF15103350 FILM CAP. 0.01UF,J,M,50
V
P114 D101 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P114 D102 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P114 D103 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P114 D104 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P114 D105 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P114 D106 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P114 D107 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P114 D109 00MHD30431000 00MHD30431000 ZENER DIODE 4.3V ZENER EQUIVALENT
P114 D111 00MHD31601000 00MHD31601000 ZENER DIODE 16V ZENER EQUIVALENT
P114 D112 00MHD31601000 00MHD31601000 ZENER DIODE 16V ZENER EQUIVALENT
P114 D201 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P114 D202 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P114 D203 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
POS. NO.
13. ELECTRICAL PARTS LIST
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
