QU01 : HD64F2505FC26DV (SUB)
pin
No
Port Name
mode=7
I/O Use STBY Name Port
Setting
Note
Act. init
1 PE5 I/O O I _V_THRU L L CVBS out Thru/Convert Selector
2 PE6 I/O O I _Y/C THRU L L Y/C out Thru/Convert Selector
3 PE7 I/O O I _MA_THRU L L Multi A Thru/OSD Selector
4 PD0 I/O O I _MB_THRU L L Multi B Thru/OSD Selector
5 PD1 I/O I I DET_OUT - - H sync Senser(only SR-11S1)
6 PD2 I/O O I COMP_THRU H L Component out Thru/Convert Selector
(only SR-11S1)
7 PD3 I/O O I P0_HPRMV H
䌌
IN0 HPD SWITCH HDMI 1 HP
8 PD4 I/O O I P1_HPRMV H
䌌
IN1 HPD SWITCH HDMI 2 HP
9 PD5 I/O O I WP0 H L WRITE PROTECT IN0
10 PD6 I/O O I WP1 H L WRITE PROTECT IN1
11 PD7 I/O I I HDMI_TX_INT L H INT from HDMI TX
12 Vss I - I VSS - - GND
13 PC0 I/O I I HDMI_RX_INT L H INT from HDMI RX
14 P1Vcc I YES I VCC - - +3.3V
15 PC1 I/O O I HD+5V_SW H L +5V SWITCH for HPD
16 PC2 I/O O I HDMI_RST L H RESET for HDMI
17 PC3 I/O O I DIG_SEL_A H L Digital Selector "A"
18 PC4 I/O O I DIG_SEL_B H L Digital Selector "B"
19 PC5 I/O O I DIG_SEL_C H L Digital Selector "C"
20 PC6 I/O O I DIG_SEL_D H L Digital Selector "D"
21 PC7 I/O O I DIG_SEL_E H L Digital Selector "E"
22 PB0 I/O O I DIG_SEL_F L H Digital Selector "F" [ _AD_DATA_SELECT ]
23 PB1 I/O O I DIG_SEL_G L H Digital Selector "G"
[ _USB_DATA_SELECT ]
24 PB2 I/O O I DIG_SEL_H L H Digital Selector "H" [
_HDMI_DATA_SELECT ]
25 PB3 I/O O I DIG_SEL_I L H Digital Selector "I"
[ _1394_DATA_SELECT ]
26 PB4 I/O I I HDMI_SCDT H - SCDT IN from HDMI
27 PB5 I/O O I L/RMUTE H L FRONT L/R MUTE(need PU)
28 PB6 I/O O I CNTMUTE H L CENTER MUTE(need PU)
29 PB7 I/O O I SL/SRMUTE H L SURR. L/R MUTE(need PU)
30 PA0 I/O O I SBMUTE H L SURR. BACK MUTE(need PU)
31 PA1 I/O O I SWMUTE H L SW MUTE(need PU)
32 PA2 I/O O I MULTI1MUTE H L MULTI ROOM 1 MUTE(need PU)
33 PA3 I/O O I MULTI2MUTE H L MULTI ROOM 2 MUTE(need PU)
34 PA4 I/O O I DIG_SEL_J L H Digital Selector "J" [ _DSD_DIRECT ]
35 PA5 I/O O O VOLDATA - - Volume YAC526 DATA
36 PA6 I/O O O VOLCLK - - Volume YAC526 CLK
37 PA7 I/O O O CE_VOL L - Volume YAC526 CE
38 PH7 I/O O I MULTIAB_ON H L MULTI ROOM OUT MUTE RELAY
CONTROL
39 PH6 I/O O I _RST_FLDAC L L Reset for DAC(FL/FR)
40 PH5 I/O O I M0_DAC - H Fs/Format Cont for DAC I
2
S/CLKMODE
OUT
41 PH4 I/O O I M2_DAC - L Fs/Format Cont for DAC fs/DSD
42 PH3 I/O O I M3_DAC - -
Fs/Format Cont for DAC DATA IN PCM/DSD
43 PH2 I/O O I M4_DAC L - Fs/Format Cont for DAC CE fs/DSD
44 PH1 I/O O I CLKMODE - - CLK mode for DSD
45 PH0 I/O O I _RST_SRDAC L L Reset for DAC(SL/SR/CNT/SW)
46 PJ7 I/O O I MULTI SPK_ON H L MULTI SPK SWITCH
47 PJ6 I/O O I _RST_AD L L Reset for ADC
48 PJ5 I/O O I 2FS_AD H L FS Cont. for ADC L : 1fs, H : 2fs
49 PJ4 I/O O I DIRDIN - - DIR Control Data IN
50 PJ3 I/O I I _OVFL L - Overflow Dection(need PU)
51 PJ2 I/O O I _ATT L H ADC input attention
