NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PD14 DG16 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PD14 DG17 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PD14 DG18 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PD14 DG19 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PD14 DG20 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PD14 DY09 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PD14 DY10 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PD14 JE01 00MYT02060720 00MYT02060720 TERMINAL 2L6P 14X14 BLK/AU B/CIRCUI
T
PD14 JE02 00MYT02060720 00MYT02060720 TERMINAL 2L6P 14X14 BLK/AU B/CIRCUI
T
PD14 JG01 00MYT02011750 00MYT02011750 TERMINAL YKC21-3479N 1L1P FG AU
PD14 JG02 00MYT02041330 00MYT02041330 TERMINAL YKC21-3601 2L4P FG BK AU
PD14 JM05 00MYT02041280 00MYT02041280 TERMINAL 14X14 RA 2L4 WH+RE AU F-FROUND
PD14 JQ04 00MYT02060720 00MYT02060720 TERMINAL 2L6P 14X14 BLK/AU B/CIRCUI
T
PD14 LE01 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24USR
PD14 LE02 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24USR
PD14 LG01 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24USR
PD14 LG02 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24USR
PD14 LM01 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24USR
PD14 QD01 00MHC10024880 00MHC10024880 IC CS4397-KSZ
(
PB FREE
)
PD14 QD03 00MHC10024880 00MHC10024880 IC CS4397-KSZ
(
PB FREE
)
PD14 QD05 00MHC10024880 00MHC10024880 IC CS4397-KSZ
(
PB FREE
)
PD14 QD07 00MHC10024880 00MHC10024880 IC CS4397-KSZ
(
PB FREE
)
PD14 QD11 00MHC008205K0 00MHC008205K0 IC TC74VHC08FT
PD14 QD12 00MHC008205K0 00MHC008205K0 IC TC74VHC08FT
PD14 QE01 00MHC10016640 00MHC10016640 IC YAC526-EZE2
PD14 QE02 00MHC10016640 00MHC10016640 IC YAC526-EZE2
PD14 QE03 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QE04 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QE05 00MHX600082A0 00MHX600082A0 CHIP TRS. KTA701U-Y/GR-RTK/P PNPX2
PD14 QE06 00MHX600082A0 00MHX600082A0 CHIP TRS. KTA701U-Y/GR-RTK/P PNPX2
PD14 QE07 00MHX800082A0 00MHX800082A0 CHIP TRS. KTC801U-Y/GR-RTK/P NPNX2
PD14 QE08 00MHX800082A0 00MHX800082A0 CHIP TRS. KTC801U-Y/GR-RTK/P NPNX2
PD14 QE09 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517S-GR
PD14 QE10 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517S-GR
PD14 QE11 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911S-GR
PD14 QE12 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911S-GR
PD14 QE13 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QE14 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QE15 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QE16 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QE17 00MHX600082A0 00MHX600082A0 CHIP TRS. KTA701U-Y/GR-RTK/P PNPX2
PD14 QE18 00MHX600082A0 00MHX600082A0 CHIP TRS. KTA701U-Y/GR-RTK/P PNPX2
PD14 QE19 00MHX800082A0 00MHX800082A0 CHIP TRS. KTC801U-Y/GR-RTK/P NPNX2
PD14 QE20 00MHX800082A0 00MHX800082A0 CHIP TRS. KTC801U-Y/GR-RTK/P NPNX2
PD14 QE21 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517S-GR
PD14 QE22 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517S-GR
PD14 QE23 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911S-GR
PD14 QE24 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911S-GR
PD14 QE25 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QE26 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QE27 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PD14 QE28 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PD14 QE30 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PD14 QE31 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PD14 QG01 00MHC10016640 00MHC10016640 IC YAC526-EZE2
PD14 QG02 00MHC10016640 00MHC10016640 IC YAC526-EZE2
PD14 QG03 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QG04 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
PD14 QG05 00MHX600082A0 00MHX600082A0 CHIP TRS. KTA701U-Y/GR-RTK/P PNPX2
PD14 QG06 00MHX600082A0 00MHX600082A0 CHIP TRS. KTA701U-Y/GR-RTK/P PNPX2
PD14 QG07 00MHX800082A0 00MHX800082A0 CHIP TRS. KTC801U-Y/GR-RTK/P NPNX2
PD14 QG08 00MHX800082A0 00MHX800082A0 CHIP TRS. KTC801U-Y/GR-RTK/P NPNX2
PD14 QG09 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517S-GR
PD14 QG10 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517S-GR
PD14 QG11 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911S-GR
PD14 QG12 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911S-GR
PD14 QG13 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
247
