Marantz SR9600 - Page 199

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PF14 CFY1
/
U1G ns
p
00MDD99030300 CER. CAP. 3 PF +-0.1 PF CJ 50
V
PF14 CFY2
/
F N ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 CFY2
/
N1B ns
p
00MDD99070300 CER. CAP. 7PF +-0.1PF CH 50
V
PF14 CFY2
/
N1G ns
p
00MDD99070300 CER. CAP. 7PF +-0.1PF CH 50
V
PF14 CFY2
/
N1S ns
p
00MDD99070300 CER. CAP. 7PF +-0.1PF CH 50
V
PF14 CFY2
/
U1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 CFY2
/
U1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 CFY3
/
F N ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 CFY3
/
N1B ns
p
00MDD99070300 CER. CAP. 7PF +-0.1PF CH 50
V
PF14 CFY3
/
N1G ns
p
00MDD99070300 CER. CAP. 7PF +-0.1PF CH 50
V
PF14 CFY3
/
N1S ns
p
00MDD99070300 CER. CAP. 7PF +-0.1PF CH 50
V
PF14 CFY3
/
U1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 CFY3
/
U1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 CFY4 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103
K
PF14 CFY5 ns
p
00MDK96473200 CER. CAP. 0.047 UF +-10 % X7R 16
V
PF14 FF01 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PF14 FF02 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PF14 FF03 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PF14 FF04 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PF14 JF01 00MYT02030540 00MYT02030540 TERMINAL 3P RCA JACK 1L3 R/G/B GOLD
PF14 JF02 00MYT02030540 00MYT02030540 TERMINAL 3P RCA JACK 1L3 R/G/B GOLD
PF14 JF03 00MYT02030540 00MYT02030540 TERMINAL 3P RCA JACK 1L3 R/G/B GOLD
PF14 JF04 00MYT02030540 00MYT02030540 TERMINAL 3P RCA JACK 1L3 R/G/B GOLD
PF14 JF06 00MYT02060740 00MYT02060740 TERMINAL YKC21-4327N
PF14 LF11 00MLU12223010 00MLU12223010 CHIP INDUCTANCE NL322522-220
K
PF14 LF12 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 LF13 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 LF14 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 LF15 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 LF16 00MLU12223010 00MLU12223010 CHIP INDUCTANCE NL322522-220
K
PF14 LF17 00MLU12223010 00MLU12223010 CHIP INDUCTANCE NL322522-220
K
PF14 LF21 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 LF22 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 LF23 00MLU12223010 00MLU12223010 CHIP INDUCTANCE NL322522-220
K
PF14 LF24 00MLU12223010 00MLU12223010 CHIP INDUCTANCE NL322522-220
K
PF14 LF25 00MLU12223010 00MLU12223010 CHIP INDUCTANCE NL322522-220
K
PF14 LF31 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 LF32 00MLU12153010 00MLU12153010 CHIP INDUCTANCE NL322522-150
K
PF14 LF33 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PF14 LF34 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PF14 LF35 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PF14 LF36 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 LF37 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PF14 QF01 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF14 QF02 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF14 QF03 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF14 QF04 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF14 QF05 00MHC12244090 00MHC12244090 IC NJM2584M 50MHZ VIDEO S
W
PF14 QF06 00MHC12244090 00MHC12244090 IC NJM2584M 50MHZ VIDEO S
W
PF14 QF07 00MHC10236090 00MHC10236090 IC NJM2586AM-TE1
PF14 QF08 00MHC10239090 00MHC10239090 IC NJM2581M-TE1
PF14 QF09 00MHC805100Z0 00MHC805100Z0 IC 74HC4051 FLA
T
PF14 QF10 00MHC809449R0 00MHC809449R0 IC 74HC4094B
T
PF14 QF11 00MHC809449R0 00MHC809449R0 IC 74HC4094B
T
PF14 QF12 00MHC98818990 00MHC98818990 IC NCP1117STAT3 1.25-18.8V ADJ REG.800M
A
PF14 QF13 00MHC10397030 00MHC10397030 IC LA7217M SINGNAL SE93221189868
2
PF14 QF31 00MHC10235090 00MHC10235090 IC NJM2285M-TE1
PF14 QF32 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF14 QF33 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
TE85L / 2SA1576A
(
Q,R
)
PF14 QF34 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
TE85L / 2SA1576A
(
Q,R
)
PF14 QF35 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
TE85L / 2SA1576A
(
Q,R
)
PF14 QF36 00MHC10472050 00MHC10472050 IC TC90A49PG
PF14 QF37 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF14 QF38 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
TE85L / 2SA1576A
(
Q,R
)
PF14 QF39 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF14 QF40 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
TE85L / 2SA1576A
(
Q,R
)
PF14 QF41 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
