Marantz SR9600 - Page 203

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PF14 RFV5 ns
p
00MNN05123610 CHIP RES. 12K OHM +- 5% 1/16
W
PF14 RFV6 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFV7 ns
p
00MNN05471610 CHIP RES. 470 OHM +- 5% 1/16
W
PF14 RFV8 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFV9 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFW1 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PF14 RFW2 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFW3 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFW4 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFW6 ns
p
00MNN05750610 CHIP RES. 75 OHM +-5% 1/16
W
PF14 RFW7 ns
p
00MNN05391610 CHIP RES. 390 OHM +- 5% 1/16
W
PF14 RFW8 ns
p
00MNN05471610 CHIP RES. 470 OHM +- 5% 1/16
W
PF14 RFW9 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFX2 ns
p
00MNN05750610 CHIP RES. 75 OHM +-5% 1/16
W
PF14 RFX3 ns
p
00MNN05391610 CHIP RES. 390 OHM +- 5% 1/16
W
PF14 RFX4 ns
p
00MNN05471610 CHIP RES. 470 OHM +- 5% 1/16
W
PF14 RFX5 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFX7 ns
p
00MNN05750610 CHIP RES. 75 OHM +-5% 1/16
W
PF14 RFX8 ns
p
00MNN05391610 CHIP RES. 390 OHM +- 5% 1/16
W
PF14 RFX9 ns
p
00MNN05471610 CHIP RES. 470 OHM +- 5% 1/16
W
PF14 RFY1 ns
p
00MNN05154610 CHIP RES. 150K OHM +- 5% 1/16
W
PF14 RFY4
/
N1B ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFY4
/
N1G ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFY4
/
N1S ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFY5
/
N1B ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFY5
/
N1G ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFY5
/
N1S ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PF14 RFY6
/
FN ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFY6
/
U1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFY6
/
U1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ1
/
FN ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ1
/
U1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ1
/
U1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ2
/
N1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ2
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ2
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ4
/
FN ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ4
/
U1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 RFZ4
/
U1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PF14 XF11 00MFQ05033010 00MFQ05033010 CER. VIB. CSB503F2 CERAMIC RESONATOR
PF14 XF12 00MJX0302035
0
00MJX0302035
0
X'TAL SMD-49 3.579545MH
Z
PF14 XF13
/
N1B 00MJX0400935
0
00MJX0400935
0
X'TAL SMD-49 4.433619MH
Z
PF14 XF13
/
N1G 00MJX0400935
0
00MJX0400935
0
X'TAL SMD-49 4.433619MH
Z
PF14 XF13
/
N1S 00MJX0400935
0
00MJX0400935
0
X'TAL SMD-49 4.433619MH
Z
PF14 XF21 00MJX2400435
0
00MJX2400435
0
X'TAL SMD-49 24.576MH
Z
PF14 XF31 00MJX1400535
0
00MJX1400535
0
X'TAL 14.31818MHZ SMD-49 FOR LC7473
2
PF14 XF32
/
N1B 00MJX1700235
0
00MJX1700235
0
X'TAL 17.734475MHZ FOR LC74732
PF14 XF32
/
N1G 00MJX1700235
0
00MJX1700235
0
X'TAL 17.734475MHZ FOR LC74732
PF14 XF32
/
N1S 00MJX1700235
0
00MJX1700235
0
X'TAL 17.734475MHZ FOR LC74732
CVBS Y/C PWB
(
00MWG12AJ501-
)
PL14 CL01 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PL14 CL02 ns
p
00MOA47700620 ELECT. CAP. 470 UF M 6.3V RA-2
PL14 CL03 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PL14 CL04 ns
p
00MOA47700620 ELECT. CAP. 470 UF M 6.3V RA-2
PL14 CL05 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PL14 CL06 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104
K
PL14 CL07 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PL14 CL08 ns
p
00MOA47700620 ELECT. CAP. 470 UF M 6.3V RA-2
PL14 CL09 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PL14 CL10 ns
p
00MOA47700620 ELECT. CAP. 470 UF M 6.3V RA-2
PL14 CL11 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PL14 CL12 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104
K
PL14 CL13 ns
p
00MDD95680300 CER. CAP. 68PF
(
GR39
)
PL14 CL14 ns
p
00MOA47700620 ELECT. CAP. 470 UF M 6.3V RA-2
PL14 CL15 ns
p
00MDD95680300 CER. CAP. 68PF
(
GR39
)
PL14 CL16 ns
p
00MOA47700620 ELECT. CAP. 470 UF M 6.3V RA-2
PL14 CL17 ns
p
00MDD95680300 CER. CAP. 68PF
(
GR39
)
261
