Marantz SR9600 - Page 209

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PP34 CP80 ns
p
00MDD15470300 CER. CAP. 47PF J CH 50V BL
K
PP34 CP81 ns
p
00MDD15470300 CER. CAP. 47PF J CH 50V BL
K
PP34 FP01 00MFN20020010 00MFN20020010 EMI FILTER ZJY51R5-4P-01
PP34 JP62 00MYT02011730 00MYT02011730 TERMINAL YKF51-5584 1P Y/C TOP
PP34 JP63 00MYT02060760 00MYT02060760 TERMINAL YKC21-5931N
PP34 LP60 00MLC11043900 00MLC11043900 CHOKE COIL SUBSTITUTE COIL 100UH J%
PP34 QP60 00MHC700400D0 00MHC700400D0 IC 74HC04 DIP
PP34 QP61 00MHC10008090 00MHC10008090 IC NJM4558D-D
PP34 RP60 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
PP34 RP61 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
PP34 RP62 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
PP34 RP63 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
PP34 RP64 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PP34 RP65 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PP34 RP66 ns
p
00MGD05750160 RES. 75 OHM +- 5% 1/6
W
PP34 RP67 ns
p
00MGD05750160 RES. 75 OHM +- 5% 1/6
W
PP34 RP68 ns
p
00MGD05750160 RES. 75 OHM +- 5% 1/6
W
PP34 RP73 ns
p
00MGD05100160 RES. 10 OHM +- 5% 1/6
W
PP34 RP74 ns
p
00MGD05221160 RES. 220 OHM +- 5% 1/6
W
PP34 RP75 ns
p
00MGD05221160 RES. 220 OHM +- 5% 1/6
W
PP34 RPV1 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PP34 RPV2 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PP34 SPV1 00MSR02010070 00MSR02010070 ROTARY SW ROTALY ENCODER 36PULSE EC16B
OPT PWB
(
00MWA11AJ404-
)
PP44 JP61 00MYJ1500027
0
00MYJ1500027
0
OPT. CONN. TORXL141
(
F
)
HEADPHONE PWB
(
00MWA11AJ407-
)
PP74 CPH1 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APS
V
PP74 CPH2 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APS
V
PP74 JPH1 00MYJ0100424
0
00MYJ0100424
0
JACK HLJ2307-01-3160
FUNCTION PWB
(
00MWG12AJ801-
)
PS14 CI03 00MOF15102540 00MOF15102540 FILM CAP. 1000PF J 100V APS
V
PS14 CI05 00MOF15102540 00MOF15102540 FILM CAP. 1000PF J 100V APS
V
PS14 CI10 00MOF15102540 00MOF15102540 FILM CAP. 1000PF J 100V APS
V
PS14 CI12 00MOF15102540 00MOF15102540 FILM CAP. 1000PF J 100V APS
V
PS14 CI15 ns
p
00MDK18103310 CER. CAP. 0.01UF Z 50
V
PS14 CI16 ns
p
00MDK18103310 CER. CAP. 0.01UF Z 50
V
PS14 CI17 ns
p
00MDK18103310 CER. CAP. 0.01UF Z 50
V
PS14 CI18 ns
p
00MDK18103310 CER. CAP. 0.01UF Z 50
V
PS14 CI20 00MEA10802510 00MEA10802510 ELECT CAP. 1000UF/ 25
V
PS14 CI21 00MEA10802510 00MEA10802510 ELECT CAP. 1000UF/ 25
V
PS14 CI22 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PS14 CI23 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PS14 CI24 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CI25 ns
p
00MOA47702520 ELECT. CAP. 470UF 25V M RA-2
PS14 CI26 ns
p
00MOA47702520 ELECT. CAP. 470UF 25V M RA-2
PS14 CI27 00MEA10802510 00MEA10802510 ELECT CAP. 1000UF/ 25
V
PS14 CI28 00MEA10802510 00MEA10802510 ELECT CAP. 1000UF/ 25
V
PS14 CI29 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PS14 CI30 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PS14 CI31 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CI32 ns
p
00MOA47702520 ELECT. CAP. 470UF 25V M RA-2
PS14 CI33 ns
p
00MOA47702520 ELECT. CAP. 470UF 25V M RA-2
PS14 CI34 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
PS14 CI35 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
PS14 CI36 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PS14 CI37 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PS14 CI40 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PS14 CI41 ns
p
00MOA47701620 ELECT. CAP. 470UF 16V M RA-2
PS14 CI42 ns
p
00MOA47701620 ELECT. CAP. 470UF 16V M RA-2
PS14 CI43 ns
p
00MOA47701620 ELECT. CAP. 470UF 16V M RA-2
PS14 CI44 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
PS14 CI45 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
PS14 CI46 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
PS14 CK01 ns
p
00MDD95471300 CER. CAP. GRM39CH471J50P
T
PS14 CK02 ns
p
00MDD95471300 CER. CAP. GRM39CH471J50P
T
PS14 CK04 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PS14 CK05 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
267
