Marantz SR9600 - Page 223

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PV24 CV60 ns
p
00MDK96474200 CER. CAP. 0.47UF/10V B
(
BJ
)
+-10%
PV24 CV61 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104
K
PV24 CV62 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104
K
PV24 CV63 00MEY10701020 00MEY10701020 ELECT CAP. 100UF/ 10V
PV24 CV64 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104
K
PV24 CV65 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104
K
PV24 CV66 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104
K
PV24 CV67 00MEY10701020 00MEY10701020 ELECT CAP. 100UF/ 10V
PV24 CV91 00MEY22700690 00MEY22700690 ELECT CAP.
220UF/6.3V LOW LEAKAGE
PV24 CV92 00MEY22700690 00MEY22700690 ELECT CAP.
220UF/6.3V LOW LEAKAGE
PV24 CV93 00MEY10601620 00MEY10601620 ELECT CAP. 10UF/ 16V
PV24 CV95 ns
p
00MDK96102300 CER. CAP. 1000 PF +- 10 % B 50V GR3
6
PV24 CV96 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104
K
PV24 FO01 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PV24 FV01 00MFN21000080 00MFN21000080 EMI FILTER DLW21HN121SQ2
PV24 FV02 00MFN21000080 00MFN21000080 EMI FILTER DLW21HN121SQ2
PV24 FV03 00MFN21000080 00MFN21000080 EMI FILTER DLW21HN121SQ2
PV24 FV04 00MFN21000080 00MFN21000080 EMI FILTER DLW21HN121SQ2
PV24 FV11 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PV24 FV12 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PV24 FV41 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PV24 FV91 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PV24 FV92 00MFN31060010 00MFN31060010 EMI FILTER BLM41P600S P
T
PV24 FV93 00MFN31060010 00MFN31060010 EMI FILTER BLM41P600S P
T
PV24 JV01 00MYJ9001466
0
00MYJ9001466
0
JACK CSS5004-1062F 1394 4P CONNECTOR
PV24 JV02 00MYJ9001466
0
00MYJ9001466
0
JACK CSS5004-1062F 1394 4P CONNECTOR
PV24 LO51 00MLU15103010 00MLU15103010 CHIP INDUCTANCE NL252018 10UH
PV24 QO01 80M11AJA00101 80M11AJA00101 U-PRO
HD64F2367VF33V 1394 CPU
PV24 QO02 80M11AJA00201 80M11AJA00201 U-PRO
M29W800DT70N1 1394 FLASH
PV24 QO14 00MHC011705K0 00MHC011705K0 IC TC74LCX00FT
(
EL.K
)
PV24 QO15 00MHC009405K0 00MHC009405K0 IC TC74VHC125F
T
PV24 QO51 00MHC005805K0 00MHC005805K0 IC TC74VHC157F
T
PV24 QO52 00MHC005805K0 00MHC005805K0 IC TC74VHC157F
T
PV24 QO53 00MHC011605K0 00MHC011605K0 IC TC74VHC161FT
(
EL
)
PV24 QO54 00MHC005805K0 00MHC005805K0 IC TC74VHC157F
T
PV24 QV01 00MHC10142370 00MHC10142370 IC TSB43CA42PGF ICELYNX-MICRO
PV24 QV03 00MHC12250990 00MHC12250990 IC W986416DH-7 -> W9864G6EH-7
(
PBFREE
)
PV24 QV41 00MHC10021660 00MHC10021660 IC PD8112A FLOW RATE CONTROL
PV24 QV42 00MHC10084090 00MHC10084090 IC NJM2107F JRC
PV24 QV91 00MHC98818990 00MHC98818990 IC NCP1117STAT3 1.25-18.8V ADJ REG.800M
A
PV24 QV95 00MHC10114530 00MHC10114530 IC S-80810CNNB-B9O-T2 1.0V DTC.
PV24 QV96 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
PV24 QV97 00MBA12303000 00MBA12303000 TRS. DTA124EU,RN2303 UMT TYPE
PV24 QV98 00MBA12303000 00MBA12303000 TRS. DTA124EU,RN2303 UMT TYPE
PV24 RO01 00MBW05103350 00MBW05103350 RES. COMPO. CN1J4TTD103J 10K OHM +/- 5% X
4
PV24 RO03 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO04 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO05 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO06 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO07 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO08 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
PV24 RO09 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PV24 RO10 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
PV24 RO11 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO12 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO13 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO14 00MBW05101350 00MBW05101350 RES. COMPO. CN1J4TTD101J 100 OHM X
4
PV24 RO15 ns
p
00MNN05104610 CHIP RES. 100K OHM +- 5% 1/16
W
PV24 RO16 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
PV24 RO17 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
PV24 RO18 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
PV24 RO19 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
PV24 RO20 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
PV24 RO21 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
PV24 RO22 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PV24 RO23 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PV24 RO24 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
