Marantz SR9600 - Page 227

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PW24 JW12 00MYP11000220 00MYP11000220 PLUG DZ101A1-B2
PW24 JW13 00MYJ0100479
0
00MYJ0100479
0
JACK HSJ1002-016010
PW24 JW14 00MYJ0100479
0
00MYJ0100479
0
JACK HSJ1002-016010
PW24 LW03 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW08 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW09 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW10 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW11 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW12 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW13 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW14 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW15 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW16 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW17 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW18 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW19 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW20 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW21 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW22 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW23 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW24 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 LW25 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PW24 QW01 80M11AJ500101 80M11AJ500101 U-PRO
HD64F2505FC26DV MAIN CPU
PW24 QW02 00MHC10204990 00MHC10204990 IC ST202ECWR OR HIN202ECB-TE2
PW24 QW03 00MHC10009980 00MHC10009980 IC S-80828CNUA-B8N-T2
PW24 QW04 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW05 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
PW24 QW06 00MHC10476990 00MHC10476990 IC AT24C32AN-10SU-2.7
PW24 QW07 00MHC705200Z0 00MHC705200Z0 IC 74HC4052 16PIN FP
PW24 QW08 00MHC10384050 00MHC10384050 IC TC7S66FU
PW24 QW09 00MHW10005210 00MHW10005210 PHOTO UNIT RPM6936 IR RECEIVER 36KH
Z
PW24 QW10 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW11 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW12 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW13 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW14 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW15 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW16 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW17 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PW24 QW18 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW19 00MHT600141B0 00MHT600141B0 TRS. KTA1271 PNP TRANSISTOR RANK=Y
PW24 QW20 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
PW24 QW21 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW22 00MHT600141B0 00MHT600141B0 TRS. KTA1271 PNP TRANSISTOR RANK=Y
PW24 QW23 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
PW24 QW24 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW25 00MHT600141B0 00MHT600141B0 TRS. KTA1271 PNP TRANSISTOR RANK=Y
PW24 QW26 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
PW24 QW27 00MBA10026210 00MBA10026210 TRS. DTA114EU
PW24 QW28 00MHT600141B0 00MHT600141B0 TRS. KTA1271 PNP TRANSISTOR RANK=Y
PW24 QW29 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
PW24 QW30 00MHW10006320 00MHW10006320 PHOTO UNIT !PC-817 PHOTO CUPLER 1PAIR
PW24 QW31 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
PW24 QW32 00MHC10440050 00MHC10440050 IC TC7SH08FU 932211931682
PW24 QW33 00MHC007505K0 00MHC007505K0 IC TC74VHCT08AFT EL X4 2INPUT AND
PW24 RW01 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PW24 RW02 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PW24 RW03 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PW24 RW04 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PW24 RW05 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PW24 RW06 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PW24 RW07 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PW24 RW08 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PW24 RW09 ns
p
00MNN05332610 CHIP RES. 3.3K OHM +- 5% 1/16
W
PW24 RW10 ns
p
00MNN05682610 CHIP RES. 6.8K OHM +- 5% 1/16
W
PW24 RW11 ns
p
00MNN05474610 CHIP RES. 470K OHM +- 5% 1/16
W
PW24 RW12 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
