PRIMER DEPTH – This setting allows you to adjust the primer seating depth and the swage if
using the SWAGE it accessory, there are 50 Increments 0-50, 0 being maximum depth, 50
being minimum. We recommend you to gauge your brass when using this setting and be-careful
not to back it off too much. There are have been different versions of the 650 primer punch over
the years, if you have an older version you will need to increase the primer depth setting to
achieve a proper primer depth.
WARNING – Always use caution when adjusting the Primer depth setting. If adjustments
are needed only use the single cycle command and adjust in small increments. We do
not recommend using Federal primers on the XL 650.
MOVE TO TOP and MOVE TO BOTTOM – These commands will drive the platform assembly
to the top position and to the bottom position. This is helpful for setting up dies in the tool head
and checking the primer punch and or swage-it rod engagement into the shell plate. These
commands will only run from the HOME position. Return from the TOP or BOTTOM position by
pressing end cycle.
RUN, END CYCLE, and STOP functions have the same functionality on the Setup Screen as
they do on the Control Screen and the Monitors Screen
