General Maintenance
The crank on the autodrive has 2 roller bearings that should be repacked with grease regularly.
Use a syringe to insert grease in the locations shown below. Also re-pack the small pin in the
upper crank. When servicing the crank always check all crank screws and set screws for
tightness.
Figure 58: Bearing Grease Points
Storage
The following is the proper procedure for storage after a session of use:
1. Ensure that the shell plate is clear of any brass
2. Check the need for lubrication after every session and apply it as necessary at the key
lubrication points outlined in the Dillon Precision manual. Insufficient lubrication creates
a potentially dangerous situation and may lead to unreliable results
3. Turn off the power to the console of the autodrive
4. Turn off the power to the case feeder and the bullet feeder
5. Turn off the power to the tablet
