14. EMI Filter for Dillon Case feeder
We have found some of the brushed AC motors and microswitches in the Dillon case feeder produce
more noise than others. If your system is experiencing electrical interference we recommend installing
the RC filter and microswitch Assy. The RC filter provided is pre-crimped with spade terminals to
minimize the installation. It plugs directly into the Dillon case feeder on/off switch. No wiring cutting or
special tools required.
Figure 28: Case Feeder RC Filter
WARNING – Use of the RC filter is at your risk and only for those experienced with electrical systems and
is only for the systems that are experiencing interference*.
