marposs P1 - P1 GENERAL EQUIPMENT DESCRIPTION; Unit Configuration Determination

Instruction Manual
18
P1
– Instruction Manual
5 P1 GENERAL EQUIPMENT DESCRIPTION
5.1 Equipment configurations
The content of this manual concerns all the configurations of P1, therefore only the sections relevant to the
specific application must be consulted.
The configuration of the P1 electronic amplifier in use is determined based both on code no. (reported on
the plate found on the rear panel) and on coding plan.
Coding plan of
P1
Code N.:
883H 0 M R F S P
Description
Code
“
H
” Hardware composition
 without casing

with casing
4
5
“
M
” measurement type
 measurement with 1 transducer (+ sign)
 measurement with 1 transducer (– sign)
 measurement with 2 transducers (+T1, +T2)
 measurement with 2 transducers (-T1, -T2)
 measurement with 2 transducers (+T1, -T2)
 measurement with 2 transducers (-T1, +T2)
0
1
2
3
4
5
“R”
0
“F” adjustment range of zero-setting potentiometer
 +/- 500 micron (+/- .020”)
 +/- 100 micron (+/- .004”)
1
2
“S” types of meter scale
 scale in metric, white
 scale in metric, yellow
 scale in metric/inches, white
 scale in metric/inches, yellow
 scale in inches, white
0
1
2
3
4
“
P
”
0
