marposs P1 - P1 Technical Specifications

Instruction Manual
P1
Instruction Manual
21
5.4 General technical specifications
STRUCTURE
Case or panel mounted
CHANNELS
1 or 2 channels
For connection to Marposs LVDT
MEASURING CYCLES
In-Process grinding check
MEASUREMENT RANGE
(In-process cycle)
Depending on the analogue instrument scale:
50-0-10 (+500 to -100 μm)
N.B.: Also available in inches or combined
µm/inches
versions
POWER SUPPLY
100-230 V a.c., r.m.s (±10%), 50-60Hz
POWER On/Off LED
0.2 A max.
WORKING TEMPERATURE
5° ÷ 40° C / 41°F ÷ 104°F
STORAGE TEMPERATURE
-20° to 70° C / -4°F to 158°F
WEIGHT
1.7 Kg (panel version)
2.5 Kg (cabinet version)
PROTECTION DEGREE
(Standard IEC 60529)
IP30
MACHINE LOGIC INTERFACE (I/O)
Opto-isolators, 24 V d. c. (See section 6.4)
ELECTRICAL SAFETY STANDARD
EN 61010-1
ELECTRO-MAGNETIC COMPATIBILITY
EN 61326-1
ENVIRONMENTAL CONDITIONS
For internal use
