39296/9527H-0320
11
SYMPTOM POTENTIAL CAUSES NEXT STEPS
Battery run time significantly
reduced
• Battery not fully charged.
• Battery damaged.
• Battery capacity effected.
• Check battery charge level indicator.
• Check battery is fully charged.
• Contact Masimo service. (See Contacting Masimo section).
Battery not charging after plugged
into AC power source
• Battery is completely depleted.
• Check the Rad-G is ON during recharging if the battery is completely depleted.
• Contact Masimo service. (See Contacting Masimo section).
SPECIFICATIONS
Display Range
MEASUREMENT DISPLAY RANGE
SpO
2 (Functional Oxygen Saturation) 0% to 100%
PR (Pulse Rate) 25 BPM to 240 BPM
Pi (Perfusion Index) 0.00 to 20.0
RRp (Respiration Rate from the Pleth) 4 RPM to 90 RPM
The emitted wavelengths range from 600 nm to 1000 nm and the peak optical power is less
than 15 mW. Information about the wavelength range can be especially useful to clinicians.
Resolution
PARAMETER RESOLUTION
SpO
2 (Functional Oxygen Saturation) 1%
PR (Pulse Rate) 1 BPM
Pi (Perfusion Index) 0.01
RRp (Respiration Rate) 1 RPM
Accuracy (Arms)
OXYGEN SATURATION SpO2
No Motion [1] (SpO
2 from 70% to 100%) Adults, Pediatrics, Infants 2%
Motion [2] (SpO
2 from 70% to 100%) Adults, Pediatrics, Infants 3%
Low perfusion [3] (SpO
2 from 70% to
100%)
Adults, Pediatrics, Infants 2%
PULSE RATE (PR)
Range 25 BPM to 240 BPM
No Motion Adults, Pediatrics, Infants 3 BPM
Motion [4] Adults, Pediatrics, Infants 5 BPM
Low perfusion Adults, Pediatrics, Infants 3 BPM
RESPIRATORY RATE RRP 5, 6, 7
Range of 4 to 90 RPM 1 RPM
* A
rms accuracy is a statistical calculation of the difference between device measurements and reference measurements. Approximately two-thirds of the device measurements fell within +/- Arms of
the reference measurements in a controlled study.
Note: A functional tester cannot be used to assess the accuracy of Rad-G.
Electrical
AC POWER REQUIREMENTS
AC Power requirements 100-240VAC, 50/60Hz, 0.6A
Power consumption < 6W
Battery
BATTERY
Type Lithium ion
Capacity 24 hours [8]
Charging Time 8 hours*
*Time to reach 80% capacity at 25°C ambient temperature.
Environmental
RADG DEVICE ENVIRONMENTAL CONDITIONS
Operating Temperature
While battery is charging*: 0°C to 40°C (32°F to 104°F)
While battery is NOT charging: 0°C to 50°C**
(32°F to 122°F)
Storage/Transport Temperature -20°C to 60°C (-4°F to 140°F) [9]
Operating Humidity 10% to 95%, non-condensing
Storage/Transport Humidity 10% to 95%, non-condensing
Operating Atmospheric Pressure 540 mbar to 1060 mbar (540 hPa to 1060 hPa)
*Exceeding this temperature can cause charging to stop.
**Compliance with IEC 60601-1 surface temperature requirements evaluated at 40°C.
Physical Characteristics
PHYSICAL CHARACTERISTICS
Dimensions
7.4 cm x 19.8 cm x 2.5 cm
(2.9" x 7.8" x 1.0")
Weight 0.27 kg. (0.59 lbs.)
