3-7 Masterflex SS B/T Washdown Digital Pump Drive with Advanced Connectivity
Section 3: Operation
Masterflex
To operate the pump in Time Mode:
1. Tap TIME from the Mode Selection Screen. e Time Mode Run Screen will be displayed.
2. Tap EDIT
to access the Time Mode Edit Screen.
3. Tap ON TIME to set the amount of time for each pump operation. e On Time Edit Screen will be
displayed.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time Mode Edit
Screen.
4. Tap OFF TIME to set the amount of time the pump will pause between each operation. e O Time
Edit Screen will be displayed. NOTE: If the o time is set to 0 (zero) the pump drive will require a start
input (from either the touchscreen or a wired input) to start the next dispense.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time Mode Edit
Screen.
5. Tap FLOW RATE. e Flow Rate Edit Screen will be displayed.
a. Tap UNITS to access the Flow Units Screen and select the desired ow unit from the available list.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the previous screen.
c. Tap FLOW and enter the desired ow rate using the onscreen keypad.
d. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time Mode Edit
Screen.
6. Tap SIZE. e Tube Size Screen will be displayed.
a. Select the desired tube size from the list of available options.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time Mode Edit
Screen.
7. Tap BATCH TOTAL to adjust the number of dispenses in each batch cycle. e Batch Total Screen will
be displayed.
a. Enter the desired number of dispenses in a batch using the onscreen keypad. NOTE: If required, tap
INFINITE ∞ to select an in nite number of dispense cycles. If in nite is selected, the pump will run
continuously.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time Mode Edit
Screen.
8. Tap CONFIRM
to return to the Time Dispense Mode Run Screen.
9. Tap DIRECTION to select either clockwise
or counterclockwise ow direction.
10. Tap START
. e pump will now operate until the batch total is completed or until PAUSE or
STOP
is tapped.
11. If required, adjustments can be made to any of the Time Mode option settings during operation. To make
any adjustments:
a. Tap PAUSE
and then repeat steps 2–9 above.
b. Tap CONTINUE
to complete the pump operation once the desired changes have been made.
