Section 3: Operation
Masterflex
10. If required, adjustments can be made to any of the Volume Mode option settings during operation. To
make any adjustments:
a. Tap PAUSE
and then repeat steps 2–10 above.
b. Tap CONTINUE
to complete the pump operation once the desired changes have been made.
Saving Volume Mode Settings as a New Program
Changes made to mode parameters can be saved as a new program for easier access to frequently used settings.
NOTE: If User Management is enabled only users with authorization can create and modify programs (for
further information see "
User Management" on page 2-8).
To save mode parameters to a new program:
1. If required, edit the Volume Mode settings as desired.
2. Tap MODE NAME BANNER to return to the Mode Selection Screen.
3. Tap NEW PROGRAM. NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap
SCROLL
to view additional pages.
4. Tap VOLUME.  e Volume New Program Screen will be displayed with the last settings used in the
Volume Mode.
5. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
6. Tap CONFIRM to save or DELETE to cancel.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL
will display additional pages.
Volume Record
 e Volume Record feature can be used to record unknown  uid volumes.
General Preparation:
• Con rm the correct tubing has been selected and is properly loaded into the pump drive (for further
information see "
Loading Tubing" on page 2-10).
• Con rm all  uids and containers are ready.
• Con rm that the tubing has been calibrated by checking that Calibration Complete
is displayed on the
Volume Mode Edit Screen (for further information see "
Tube Calibration" on page 2-13).
• If required, prime the pump before operation (for further information see "
Priming the Pump Drive" on
page 2-12).
To record a  uid volume:
1. Tap VOLUME from the Mode Selection Screen.  e Volume Mode Run Screen will be displayed.
2. Tap EDIT
to access the Volume Mode Edit Screen.
3. Tap RECORD
.  e Record Dispense Screen will be displayed.
