3-13 Masterflex SS B/T Washdown Digital Pump Drive with Advanced Connectivity
Section 3: Operation
Masterflex
4. Tap FLOW RATE to make adjustments to the ow rate. e Flow Rate Screen will be displayed.
a. Tap FLOW to enter the desired ow rate using the onscreen keypad.
b. Tap UNITS to enter the desired ow rate units using the onscreen keypad.
c. Tap CONFIRM
to save changes and return to the Record Dispense Screen.
5. Tap START
. e drive will now begin pump operation while recording the uid volume.
6. If required, adjustments can be made to ow rate during operation. To make adjustments:
a. Tap STOP
and then repeat steps 4–6 above.
b. Tap START
to complete the pump operation once the desired changes have been made. NOTE:
If required, tap STOP
and then CANCEL to discard recording and return to the Volume
Mode Edit Screen.
7. Tap STOP
when the desired volume of uid has been pumped. e recorded dispense volume will
now be displayed under VOLUME.
8. Tap CONFIRM
to save or CANCEL to discard recording and return to the Volume Mode Edit
Screen. If saved, the recorded dispense volume will now be displayed under VOLUME.
9. Tap CONFIRM
. e Volume Mode Run Screen will be displayed.
