5-2 Masterflex SS B/T Washdown Digital Pump Drive with Advanced Connectivity
Section 5: Service & Maintenance
Masterflex
CLEANING THE PUMP DRIVE
!
CAUTION: Unplug the pump drive’s power cable from the mains power outlet when cleaning
or performing maintenance on the drive.
If required, the pump drive may be wiped clean using a soft cloth lightly moistened with either isopropyl or
ethyl alcohol.
NOTE:
• Care should be taken with the pump drive’s touchscreen to avoid scratching or otherwise damaging the
surface. Do not wipe with dry or abrasive material.
• Do not operate the pump drive with water on the surface of the touchscreen.
• Any damage caused by improper cleaning will be the sole responsibility of the customer.
ACCESSORIES
B/T Accessories
To purchase accessories or for further information visit www.master ex.com. e following accessories are
available for the B/T Digital Pump Drive:
Description Part Number
Footswitch with 6 ft (1.8 m) cable and 31-Pin male connector 07575-84
31-Pin male connector (no cable, connector only) 109736-CR
Cable assembly (31-Pin male connector and 25 ft (7.9 m) cable with
stripped wire ends)
07575-80
FUSE,T6.3A, 5MM X 20MM 117197
REPLACEMENT PARTS
Description Part Number
Rotor Assy 108024-CR
Spacer, Shoulder 109461-CR
Window 109467-CR
Door Assembly 109473-CR
Replacement Line Cord Assem 115V 109573-CR
Roller & Retaining Ring Kit BT 109852-CR
FUSE,T6.3A, 5MM X 20MM 117197
Cable and Switch 113333-CR
