Section 3: Operation
Masterflex
F. LOGOUT: Tap to log out a user. NOTE:  is option is only available if User Management is enabled in
Settings (for further information see "
User Management" on page 2-8).
Analog Input
!
CAUTION: Power must be turned o before connecting the external analog control cable to pre-
vent damage to the drive.
 e B/T supports and controls analog input using suitable equipment through the pump drive’s 31-Pin
female connection port. Analog input can be used in place of, or in addition to, Master exLive™.
See also "
31-Pin Electrical Connections" on page 4-5.
General Preparation:
• Con rm the correct tubing has been selected and is properly loaded into the pump drive (for further
information see "
Loading Tubing" on page 2-10).
• Con rm all  uids and containers are ready.
• Switch the drive on using the power switch located at the rear of the drive. NOTE: If User Management
is enabled you may be prompted for a username and password (For further information see "
User
Management
" on page 2-8).  e touchscreen display will revert to the previously used operation mode.
• Con rm that the tubing has been calibrated by checking that Calibration Complete
is displayed on the
Analog Input Mode Run Screen (for further information see "
Tube Calibration" on page 2-13).
• If required, prime the pump before operation (for further information see "
Priming the Pump Drive" on
page 2-12).
• Con rm that the pump drive is connected to the appropriate equipment through the drive’s 31-Pin
female connection port.
To operate analog input control and monitoring:
1. Tap ANALOG INPUT from the Mode Selection Screen.  e Analog Input Mode Run Screen will be
displayed.
2. Tap EDIT
.  e Analog Input Mode Edit Screen will be displayed.
3. Tap the desired analog input type from the available list.
4. If using either ANALOG: VOLTAGE or ANALOG: CURRENT:
a. Select the desired current or voltage operating range from the available list.
b. Tap CONFIRM
to save or CANCEL to cancel and return to the previous screen.
NOTE:
• Tap STOP
on the pump drive touchscreen to override the remote control device and immediately stop
the pump operation. NOTE: If locked, the screen will need to be unlocked before the pump operation
can be stopped.
• See
www.master ex.com for further information on using analog input remote control and monitoring.
