3-11 Masterflex SS B/T Washdown Digital Pump Drive with Advanced Connectivity
Section 3: Operation
Masterflex
To operate the pump in Volume Mode:
1. Tap VOLUME from the Mode Selection Screen. e Volume Mode Run Screen will be displayed.
2. Tap EDIT
to access the Volume Mode Edit Screen.
3. Tap VOLUME. e Dispense Volume Screen will be displayed.
a. Tap VOLUME and enter the desired volume using the onscreen keypad. NOTE: If the volume of
uid is unknown the pump drive can record uid dispense volumes (for further information see "
Vol-
ume Record
" on page 3-12).
b. Tap RAMP UP
to set the time the pump takes to reach full ow rate (between 0 and 60 seconds)
using the onscreen keypad.
c. Tap RAMP DOWN
to set the time the pump takes to stop at the end of each dispense operation
(between 0 and 60 seconds) using the onscreen keypad.
d. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume Mode
Edit Screen.
4. Tap INTERVAL TIME to set the amount of time the pump will pause between each operation. e
Interval Time Screen will be displayed. NOTE:
If the interval time is set to 0 (zero) the pump drive will
require a start input (from either the touchscreen or a wired input) to start the next dispense.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume Mode
Edit Screen.
5. Tap FLOW RATE. e Flow Rate Edit Screen will be displayed.
a. Tap UNITS to access the Flow Units Screen and select the desired ow unit from the available list.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the previous screen.
c. Tap FLOW and enter the desired ow rate using the onscreen keypad.
d. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume Mode
Edit Screen.
6. Tap SIZE. e Tube Size Screen will be displayed.
a. Select the desired tube size from the list of available options.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume Mode
Edit Screen.
7. Tap BATCH TOTAL to adjust the number of dispenses in each batch cycle. e Batch Total Screen will
be displayed.
a. Enter the desired number of dispenses in a batch using the onscreen keypad. NOTE: If required, tap
INFINITE ∞ to select an in nite number of dispense cycles. If in nite is selected, the pump will run
continuously.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume Mode
Edit Screen.
8. Tap DIRECTION to select either clockwise
or counterclockwise ow direction.
9. Tap START
. e pump will now operate until the batch total is completed or until PAUSE or
STOP
is tapped.
