iv Masterflex SS B/T Washdown Digital Pump Drive with Advanced Connectivity
Masterflex
iv
Table of Contents
Time Mode Run Screen 3-5
Time Mode Edit Screen 3-6
Time Mode Operation 3-6
Saving Time Mode Settings as a New Program 3-8
Volume Mode 3-9
Volume Mode Run Screen 3-9
Volume Mode Edit Screen 3-10
Volume Dispense Mode Operation 3-10
Saving Volume Mode Settings as a New Program 3-12
Volume Record 3-12
Analog Input Mode 3-14
Analog Input Mode Run Screen 3-14
Analog Input 3-15
Saving Analog Input Mode Settings as a New Program 3-16
Master exLive™ 3-17
Custom Program Modes 3-17
Adding a New Program: Continuous Mode 3-17
Adding a New Program: Time Mode 3-17
Adding a New Program: Volume Mode 3-19
Adding a New Program: Analog Input Mode 3-20
Using Program Modes 3-21
Editing a Program 3-21
Deleting a Program 3-22
SECTION 4: COMMUNICATION SPECIFICATION 41
Ethernet/IP Mode 4-1
Ethernet/IP Setup 4-1
Master ex Ethernet/IP 4-4
Pro bus 4-6
Pro bus Mode 4-6
Pro bus Setup 4-6
Pro bus Settings 4-6
Pro bus data 4-8
SECTION 5: SERVICE & MAINTENANCE 51
Firmware Updates 5-1
Restore Factory Settings 5-1
Cleaning the Pump Drive 5-2
Accessories 5-2
B/T Accessories 5-2
Replacement Parts 5-2
Replacing Rollers 5-3
Tubing Types 5-4
31-Pin Electrical Connections 5-5
Troubleshooting 5-6
