CHAPTER 5: ASSEMBLY INSTRUCTIONS
5.4 G7-S23 SHOULDER PRESS ASSEMBLY INSTRUCTIONS - CONTINUED
Item Description Quantity
B22 Flat Washer (M10) 1
B23 Nylon Nut (M10) 1
C10 Shaft 1
C17 Pulley Cover 1
C31 Flat Washer 4
C36 Screw (M10 x 55L) 4
D18 Bearing Cover 2
D19 Screw (M10 x 15L) 2
D27 Wave Washer 2
D28 C Clip 2
Q14 Screw (M8 x 20L) 4
Z08 Screw (M6 x 12L) 4
Z09 Flat Washer (M6) 4
Z10 Screw (M10 x 105L) 1
STEP 2
