Group
SETU VFXTH supports the following methods of determining the destination port for the calls originated on FXO
Ports, FXS Ports and SIP Trunks.
•Fixed
• on the basis of Destination Number
• on the basis of Calling Party Number
The Destination Port Determination Method- on the basis of Calling Party Number is not applicable for the
FXS Port.
For any of these methods that you select, you need to configure Routing Group and Fallback Routing Group.
A Routing Group may have sequential or not-sequential ports as members.
A Routing Group of sequential ports is to be formed when you select FXO Port or FXS Port or SIP Trunk as the
destination port.
A Routing Group of not-sequential ports is to be formed when you select SIP - Group or FXO - Group or FXS -
Group as the destination port. The SIP/FXO/FXS Group has members of the same port type, but not in a
sequence. A SIP Group can have only SIP Trunks as members. Similarly, a FXO Group can have only FXO Ports
as members.
Configuring Groups
To create a Group,
• Click Advanced Settings link.
• Click the Group link.
• To create Groups of SIP Trunks, click SIP Group. You can create 9 Groups with 9 members in each group.
• Select a SIP Group Number from 1 to 9.
