CHAPTER 2 Know Your SETU VFXTH
Overview of SETU VFXTH
SETU VFXTH is a gateway that provides voice services over IP network using SIP protocol. It is an effective and
flexible solution for accessing internet based telephone services and corporate intranet systems across established
LAN.
It is an innovative enterprise gateway that offers excellent functionality and sound quality. It supports different voice
ports viz. FXO, FXS and SIP for providing voice services.
It is a feature packed gateway to fulfill the requirements of SOHO (Small Office-Home Office) users as well as
Medium scale Enterprises.
SETU VFXTH is available in the following configurations:
*
SETU VFXTH1600 and SETU VFXTH1616 has been discontinued. However, software support is still provided through Jeeves
for the users who have already installed it.
For a complete list of Hardware and Software features, refer “Product Specifications” in the Appendix.
Sr. No. Configuration
Voice
Channels
FXO Ports FXS Ports
Physical Port Labels
FXO FXS
1 SETU VFXTH0016 16 0 16 0 P01-P16
2 SETU VFXTH0024 24 0 24 0 P01-P24
3 SETU VFXTH0032 32 0 32 0 P01-P32
4 SETU VFXTH1600* 16 16 0 P01-P16 0
5 SETU VFXTH3200 32 32 0 P01-P32 0
6 SETU VFXTH0808 16 8 8 P01-P08 P09-P16
7 SETU VFXTH1616* 32 16 16 P01-P16 P17-P32
