223 Matrix SETU VFXTH System Manual
IP Dialing
SETU VFXTH supports direct dialing of IP Addresses from the source port. To provide IP Dialing facility to the
users, you must configure a SIP Trunk or a SIP Group for IP Dialing.
When a number is dialed out from the source port, SETU VFXTH routes the call to the desired destination as per
the routing mechanism configured for that port. However, when an IP Address is dialed from the source port of
SETU VFXTH, the system does not check the Destination Port Determination method you have configured for that
port, instead it routes the dialed IP Address through the SIP Trunk or SIP Group you configured for IP Dialing.
When dialing an IP Address, users must press * key (star/asterisk) in place of. (dot/period) in the IP Address.
For example, to call the IP Address 192.167.100.1, users must dial 192*167*100*1 or 192*167*100*001
SETU VFXTH interprets the * you dialed as a '.' (dot/period).
Configuring IP Dialing
To provide this feature to users,
• you need to select a SIP Trunk or a SIP Group through which the dialed IP Address are to be routed.
If you want to use a SIP Trunk group for IP Dialing, you must configure a SIP Group first. This Group is
common for all port types. See the topic “Group” for instructions.
When you assign a SIP Trunk, make sure it is enabled and has the necessary configuration done. See
“SIP Trunks” under Basic Settings for instructions.
• assign the SIP Trunk you want or the SIP Group you configured to SIP Trunk for IP Dialing in the System
Parameters. See “System Parameters” under Advanced Settings for instructions. By default, SIP Group 1
is selected for IP Dialing in the System Parameters.
If SIP Trunk Group for IP Dialing is programmed as 'None', SETU VFXTH will give error tone to the caller
i.e. the call will be rejected.
