Matrix Visionpro System Manual

Matrix VISIONPRO System Manual 8
Ports and Connectors
LEDs
Port Description
PowerPort To connect the external power adapter of 12V@2A.
Earth To connect the telecom earth to the system.
CO To connect the CO trunk lines from PSTN.
SLT To connect station SLT phones, FAX machines.
RESET
To reset the SE and the SA Password to their respective default
values.
LED Color Description
PWR Green To indicate system power ON/OFF condition.
STS Green To indicate the system status during various conditions.

Matrix Visionpro Specifications

General

Brand	Matrix
Model	Visionpro
Category	PBX
Language	English
