Matrix VISIONPRO System Manual 24
CHAPTER 4 Configuring VISIONPRO
Configuration Modes
VISIONPRO is a flexible system and can be programmed to suit your needs. Programming can be done at three
levels: System Engineer (SE), System Administrator (SA) and User Level. A distinct set of features and facilities
can be configured at each of these levels.
It is possible to configure the VISIONPRO from any location using a phone. You can use a phone
connected to the SLT port of the VISIONPRO to configure the system On-site (where it is installed). You
can also configure the system using a phone Off-site, that is from a Remote location. You can access both
the System Engineer mode as well as the System Administrator mode from the remote location. To know
more, see “Remote Configuration”.
Each VISIONPRO variant has fixed number of station and trunk ports. Each station port has a software port and a
flexible number associated to it which are used for unique identification. Similarly, each trunk port has a software
port associated to it.
For Station ports refer to the table below:
Software Port Number for Trunk ports are 0, 1 and 2.
• Programming from SE or SA mode is based on the software port. On the other hand, programming
from the User level (like Personal Memory, Dynamic Lock etc.) is based on flexible numbers.
• You can change the default flexible numbers assigned to station software ports at any point of time.
See “Flexible Numbers” for instructions.
Flexible Number (Default) Software Port Number
21 00
22 01
23 02
24 03
25 04
26 05
27 06
28 07
